Grease Gun & Parts

It appears you don't have a PDF plugin for this browser. You can click here to download the PDF file.

Downloads

WANNER GREASE GUN

Wanner high pressure grease gun, made in Switzerland, with 0 - 600 bar glycerine gauge. Push rod style for easy grease cartridge exchange (no red piston seal required).

REPAIR GREASE GUN SERVICE

Send your grease gun to us and we will repair and return promptly.

GREASE GUN PARTS

We stock a complete inventory of parts for same day shipment.

Grease Gun and parts from Stage 14 in

Parts List

NEW VERSION PUSH ROD GREASE GUN
PART #DESCRIPTION
36590CONNECTOR
35184-13.5"13.5" HIGH PRESSURE HOSE
35184-20"20" HIGH PRESSURE HOSE
35690FILLER CAP CONICAL
83746GAUGE 0-600 BAR
80128WASHER
32325ROTARY COUPLING
80365WASHER
81394BIGGER SPRING
32344VALVE PIN
33772VALVE SEAT
82205O-RING
82666COPPER SEAL
33716NON RETURN VALVE
83398NEW LOW PRES PISTON
38148DISC FOR LOW PRES PIST
80657BARREL SEAL
38004CYLINDER
38195.04PISTON ROD COMPLETE ASSY (CONVERSION KIT)
33707LEVER
81697SMALL TORSION SPRING
84631SPIRAL PIN FOR PISTON
32340PISTON
82495X-RING
33773PRES REL SCREW SHORT
82008STEEL BALL (5/32”)
35595AIR RELEASE VALVE
80198SEAL, CU JOINT
84391SCREW FOR HANDLE (2)
33705HANDLE PLASTIC
33731GUN HEAD
38078PISTON ROD
38013COVER
38147INSET (NEW STYLE)
38004CYLINDER ONLY
81771PRESSURE SPRING
38146END SUPPORT FOR PISTON ASSY
84808SECURITY DISC
82010STEEL BALL (3/16”)
43448VALVE SEAT
33755KIT BRACKET
CHAIN VERSION GREASE GUN
PART #DESCRIPTION
N83746GAUGE
K80128WASHER
32325ROTARY COUPLING
K80365WASHER
K81384PRESSURE SPRING
K81699TORSION SPRING
N84684SPIRAL PIN
K30643VALVE PLUG
N84630SPIRAL PIN
N82495X-RING
H32340PISTON
B30508NON RETURN VALVE
K80657JOINT SEAL
H38004CYLINDER
K83576PISTON SEAL RED
K80162JOINT PAD
H32329GUIDE
B39075SUPPORT
K81763PRESSURE SPRING
N83901CHAIN .6m
N84681SPIRAL PIN
B30657END COVER
H39096LINING
N82741FLAT WASHER
K81656PRESSURE SPRING
H39095HANDLE
36590HYDR. CONNECTOR
35184HOSE
H30642COVER PLUG
K80266WASHER
H32308PRES. REL SCREW
N82010STEEL BALL
35590AIR RELEASE VALVE
K80198WASHER JOINT SEAL
ADDITIONAL PARTS FOR GREASE GUNS
PART #DESCRIPTION
30643VALVE PLUG
81384PRESSURE SPRING
32308PRES. RELEASE SCREW
30508ASPIRATION VALVE
35590AIR RELEASE VALVE
PART KITS FOR GREASE GUNS
PART#KITS / PARTS FOR GREASE GUNS
33758PRES. RELEASE VALVE KIT W/SCREW
33755KIT BRACKET
38195.04CONVERSION KIT TO ADAPT /CONVERT
CHAIN GUN TO PUSH ROD TYPE
32345SPARE PARTS KIT FOR OLD VERSION
33790SPARE PARTS KIT FOR NEW VERSION
33731.03VALVE HEAD COMPLETE
OLDER STYLE PUSH ROD GREASE GUN PARTS
PART #DESCRIPTION
83746GLYCERING GAUGE
80128WASHER
32325ROTARY COUPLING
80365WASHER
82010STEEL BALL 3/16”
81699TORSION SPRING
84684SPIRAL PIN
43448VALVE SEAT
84630PRIM PIN
82495X-RING
32340PISTON
30647.01LEVER
30614.01VALVE HEAD
48256.01ASPIRATION VLVE
80657JOINT
38080SUPPORTING DISC
38075LOW PRES. PISTON
38004CYLINDER
38089INSERT
81771PRESSURE SPRING
38013COVER
38078PISTON ROD
84808SECURITY DISC
36590HYDR. CONNECTOR*
35184PRES HOSE 20”
35184PRES HOSE 13”
35690FILLER CAP CMPLT
80266COPPER SEAL
32308.01SCREW
82010STEEL BALL 3/16”
35595.01AIR REL. VALVE
80198CU-JOINT
82250O-RING (ASP.VALVE)
82205O-RING (VALVE SEAT)
32339SPRING PIN
81358PRESSURE SPRING
